How a small or medium injection mold moves through our workshop — from the first drawing review to the packed and inspected tool sitting on a pallet.
Before any quote is confirmed, we read the drawings. We check the part for wall thickness consistency, draft, undercuts, gate positions, ejection strategy and expected shrinkage. If information is missing, we ask. If a feature is unlikely to mold cleanly, we say so and propose an alternative.
You receive a short DFM note back — sometimes a page, sometimes a marked-up screenshot. That note becomes the record of what we agreed before steel was cut.
Mold design is done in-house in UG / NX (with 2D drawings in AutoCAD). We work out parting line, gating, ejection and cooling with the same engineer who reviewed the part — not a separate design office that never sees the workshop.
Before machining starts, we send you the mold layout, gate positions, ejector plan and cooling plan for approval. Changes at this stage are cheap; changes after steel is cut are not.
Steel is selected together with you — P20 / 1.2311 for prototype and mid-life tools, 718H / 2738 for pre-hardened production, S136 / 2083 for optical or high-polish cavities, H13 / 1.2344 for high-wear zones. Material certificates travel with the tool.
CNC machining is done by long-term machining partners we have worked with for years. Our tooling engineers set the machining strategy, review the CAM programs and inspect every part before it comes back into the workshop for EDM, fitting and assembly.
EDM is in-house. Sinker EDM handles ribs, sharp corners, logos and text; wire EDM opens ejector holes and precision slots. Electrodes are prepared and inspected before burning.
Fitting and polishing are handled by mold makers who have done this work for years. Parting lines, shut-offs, slider faces and cavity surfaces are worked by hand until they meet the drawing and the surface spec.
Assembly brings core, cavity, slider, lifter, ejector and cooling together with the mold base. Every water line is pressure-tested; every slider is cycled by hand before the tool goes on a machine.
T1 trial is done in-house on our 90T–200T injection molding machines. You receive:
If the parts need a T2 (which is normal), we run T2 after the corrections and send fresh samples before the mold ships.
Before packing, the mold is cleaned, oiled and photographed — closed, opened, both halves, and the runner side. Samples travel with the mold. Documents travel with the mold.
Packing is a proper wooden case with steel banding, silica gel and rust protection. The tool is photographed inside the crate before the lid goes on.
Lead times below assume drawings are frozen at kick-off and steel is available. We confirm dates in writing after drawing review — never before.
| Type of mold | Typical lead time (design → T1) |
|---|---|
| Prototype mold, 1 cavity, part < 150 mm | 18 – 25 working days |
| Single-shot production mold, 1 cavity, part 150 – 300 mm | 30 – 40 working days |
| 1+1 or 2-cavity production mold with sliders | 35 – 45 working days |
| Multi-cavity production mold (up to 8 cavities) | 40 – 55 working days |
| Mold repair / insert replacement | 7 – 15 working days after part receipt |
